• Flow measurement with unit conversion facility.
• Material options depending upon process data.
• Media: Liquid(conductive)
• Power Supply: 90-260 V AC, 50 Hz; Optional:24V DC
• Line Size: 15NB to 600NB(for higher line please consult)
• Output: 4 to 20 mA DC: Optional: HART/Pulse/Communication port
• Transmitter Electronics: Integral/Remote with max 25mtr cable
• Accuracy: +/- 0.5% of FS (for 20 to 100 % flow)
• Material of COnstructions: As per requirement
• Transmitter Enclosure: Die cast Aluminium IP 66, flow type IP68
• Operating Pressure: Upto 10kg/cms2
• Process Connection: ASA 150 Flanged, as per table B 16.5

Ultrasonic Flowmeter

• Suitable for conductive and non conductive liquids
• No moving part, no pressure drop, no maintenance
• Insertion type/Portable type - also available for a wide range of pipesizes from DN 65mm t0 DN 6000mm
• Display: 16X2 LCD display
• Output: 4-20mA DC
• Accuracy: +/- 1.0% of FS
• Maximum permitted pressure: 1.6 Mpa, classes MAP 16
• Protection class: IP67
• Optional: RS485 communication
• Flange connection: ANSI class
